EV Exhaust Air Valves



Features

  • Suitable for offices, houses, etc, easy installation on the wall or in the ceiling
  • Manufactured from sheet steel painted white
  • Available also in Stainless steel version EV-S
  • The valve body is equiped with a cellular plastic gasket to form an air-tight seal
  • The air flow is adjusted by rotating the control disc
  • Supplied with mounting ring
  • Semi gloss finish 70%
  • Specular finish 90%
  • Packing: hardboard box in white or brown colour.

Dimensions



EV C D Box
80 115 62 42 77.5 7
100 138 75 40 97.5 7
125 164 100 46 122.5 7
150 202 120 50 147.5 7
160 211 130 54 157.5 7
200 248 158 63 197.5 7
250 305 215 75 248 7

Performance
